Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 520

Maintenance manual

Page of 907

/ 907

B--63005EN/02

6.INTERFACE BETWEEN CNC AND PMC

495

Symbol M seriesT seriesAddressSignal name

STWD Output simultaneous operation mode select signal G058#6 — f

SUCLP Spindle unclamp signal F038#1 f —

SVF1 to SVF8 Servo--off signal G126 f f

SWS1 G027#0 f —

SWS2

Spindle select signal

G027#1 f —

SWS3 G027#2 f —

SYCAL

Spindle synchronization control alarm signal/phase

error monitoring signal

F044#4 f f

SYN10 to SYN80 Synchronization control in--progress signal F118 f —

SYN10 to SYN70

Synchronization/composite/superposition control in--

progress signal

F118#0 to #6 F —

SYNC1 to SYNC8 Simple synchronization axis select signal G138 f f

SYNC1 to SYNC8

G138 f —

SYNC1 to SYNC7

ync

ron

zat

on contro

sse

ect s

gna

G138#0 to #6 F —

SYNCJ1 to SYNCJ8 Simple synchronization manual feed axis select signal G140 — f

SYNMOD EGB mode signal F065#6 — f

T00toT31 Tool function code signal F026 to F029 f f

TAP Tapping in--progress signal F001#5 f f

TF Tool function strobe signal F007#3 f f

TFIN Tool function completion signal G005#3 f f

THRD Threading in--progress signal F002#3 f f

TIALM Tool post interference alarm signal F064#7 F —

TICHK Tool post interference check in --progress signal F064#6 F —

TL01 to TL64 G047#0 to #6 f —

TL01 to TL256

Tool ground number select signal

G047#0 to

G048#0

— f

TLCH Tool change signal F064#0 f f

TLCHI Tool--by--tool change signal F064#2 — f

TLMA F045#6 f f

TLMB

Torque limit in--progress signal (serial spindle)

F049#6 f f

TLMC F168#6 f f

TLMHA G070#1 f f

TLMHB

Torque limit command high signal (serial spindle)

G074#1 f f

TLMHC G204#1 f f
