B-63944EN-2/02 PROGRAMMING 6.COMPENSATION FUNCTION

- 101 -

6.1 TOOL LENGTH COMPENSATION SHIFT TYPES

Overview

A tool length compensation operation can be performed by shifting

the program coordinate system: The coordinate system containing

the axis subject to tool length compensation is shifted by the tool

length compensation value. A tool length compensation shift type

can be selected with parameter TOS (parameter No. 5006#6). If no

move command is specified together with the G43, G44, or G49

command, the tool will not move along the axis. If a move command

is specified together with the G43, G44, or G49 command, the

coordinate system will be shifted first, then the tool will move along

the axis.

One of the following three methods is available, depending on the

type of axis that can be subject to tool length compensation:

• Tool length compensation A

Compensates the value of the tool length on the Z axis.

• Tool length compensation B

Compensates the value of the tool length on one of the X, Y, and

Z axis.

• Tool length compensation C

Compensates the value of the tool length on a specified axis.

Format

- Tool length compensation A

G43 Z_H_;

Shifts the coordinate system along the Z axis by the

compensation value, to the + side.

G44 Z_H_;

Shifts the coordinate system along the Z axis by the

compensation value, to the - side.

G43 (or G44) : + (or -) side offset at which to start tool

length compensation

H_ : Address specifying the tool length

compensation value
