2.PREPARATORY FUNCTION (G FUNCTION) PROGRAMMING B-63944EN-2/02

- 16 -

Table 2(a) G code list

G code Group Function

G40 Cutter or tool nose radius compensation : cancel

Three-dimensional cutter compensation : cancel

G41

Cutter or tool nose radius compensation : left

Three-dimensional cutter compensation : left

G41.2 Cutter compensation for 5-axis machining : left (type 1)

G41.3 Cutter compensation for 5-axis machining : (leading edge offset)

G41.4 Cutter compensation for 5-axis machining : left (type 1) (FS16i-compatible command)

G41.5 Cutter compensation for 5-axis machining : left (type 1) (FS16i-compatible command)

G41.6 Cutter compensation for 5-axis machining : left (type 2)

G42

Cutter or tool nose radius compensation : right

Three-dimensional cutter compensation : right

G42.2 Cutter compensation for 5-axis machining : right (type 1)

G42.4 Cutter compensation for 5-axis machining : right (type 1) (FS16i-compatible command)

G42.5 Cutter compensation for 5-axis machining : right (type 1) (FS16i-compatible command)

G42.6

Cutter compensation for 5-axis machining : right (type 2)

G40.1 Normal direction control cancel mode

G41.1 Normal direction control on : right

G42.1

Normal direction control on : left

G43 Tool length compensation +

G44

Tool length compensation -

G43.1 Tool length compensation in tool axis direction

G43.4 Tool center point control (type 1)

G43.5

Tool center point control (type 2)

G45 Tool offset increase

G46 Tool offset decrease

G47 Tool offset double increase

G48

Tool offset double decrease

G49 (G49.1) 08 Tool length compensation cancel

G50 Scaling cancel

G51

Scaling

G50.1 Programmable mirror image cancel

G51.1

Programmable mirror image

G50.2 Polygon turning cancel

G51.2

Polygon turning

G52 Local coordinate system setting

G53 Machine coordinate system setting

G53.1

Tool axis direction control

G54 (G54.1) Workpiece coordinate system 1 selection

G55 Workpiece coordinate system 2 selection

G56 Workpiece coordinate system 3 selection

G57 Workpiece coordinate system 4 selection

G58 Workpiece coordinate system 5 selection

G59

Workpiece coordinate system 6 selection

G60 00 Single direction positioning

G61 Exact stop mode

G62 Automatic corner override

G63 Tapping mode

G64

Cutting mode

G65 00 Macro call
