B-63944EN-2/02 PROGRAMMING 6.COMPENSATION FUNCTION

- 139 -

- Ending (canceling) cutter compensation

In cutter compensation mode, cutter compensation is canceled if a

block that satisfies at least either one of the following conditions is

executed:

<1> G40 is specified.

<2> D00 is specified as the compensation number of cutter

compensation.

If cutter compensation cancel is to be performed, it must not be by a

circular command (G02, G03). Otherwise, an alarm will occur.

For a cancel operation, one of three types, A, B, and C, can be

selected by appropriately setting parameter SUP (No. 5003#0) and

parameter SUV (No. 5003#1). The operation to be performed if the

tool turns around the inside is of a single type.

- Meaning of symbols

The following symbols are used in subsequent figures:

• S indicates a position at which a single block is executed once.

• SS indicates a position at which a single block is executed twice.

• SSS indicates a position at which a single block is executed three

times.

• L indicates that the tool moves along a straight line.

• C indicates that the tool moves along an arc.

• r indicates the cutter or tool nose radius compensation value.

• An intersection is a position at which the programmed paths of two

blocks intersect with each other after they are shifted by r.

•

indicates the center of the tool.
