6.COMPENSATION FUNCTION PROGRAMMING B-63944EN-2/02

- 222 -

- Input/output of fixture offset

The data can be programmed and can be input from and output to

external equipment, as described below:

(1) Setting the reference fixture offset by G10

G10 L21 Pn P ;

N: Refernece fixture offset number

P: Reference fixture offset or reference angle of each axis

With this command, a reference fixture offset or reference angle

can be programmed.

If the command is executed in the G90 mode, the specified value

is set directly. If the command is executed in the G91 mode, the

sum of the specified value and the previous value is set.

NOTE

The programmable data input function (G10)

function is needed.

(2) Reading/writing based on a custom macro system variable

The following system variable number can be used to read and

write a reference fixture offset value or a reference angle.

However, it is impossible to write to a system variable area (5500

to 5508) if n = 0.

System variable number = 5500 + 20 * n + m

n: Fixture offset number (1 to 8)

(The current offset is used if n = 0.)

m: Axis number (1 to number of controlled axes)

NOTE

The custom macro function is needed.

(3) Output to external units

Selecting [PUNCH] on the fixture offset screen enables

outputting to external units such as a floppy cassette and memory

card via RS-232-C.

Output data is in the G10 format with no program number.

NOTE

The reader/punch interface and programmable data

input (G10) functions are needed.

(4) Input from an external units.

Selecting [READ] on the fixture offset screen, the data can be

input from a Floppy Cassette and memory card via RS-232-C.

The data is input in the G10 form with no program number.

NOTE

The reader/punch interface function and

programmable data input functions are needed.
