3.INTERPOLATION FUNCTION PROGRAMMING B-63944EN-2/02

- 26 -

3.1.2 Helical Involute Interpolation (G02.2, G03.2)

As with arc helical involute interpolation, this function performs

helical involute interpolation on the two axes involute interpolation

and on up to four other axes simultaneously.

Format

Helical involute interpolation in Xp-Yp plane

G17

G02.2

G03.2

Xp Yp

I J R

F ;

Helical involute interpolation in Zp-Xp plane

G18

G02.2

G03.2

Zp Xp

K I R

F ;

Helical involute interpolation in Yp-Zp plane

G19

G02.2

G03.2

Yp Zp

J K R

F ;

α, β, γ, δ: Optional axis other than the axes of involute interpolation.

Up to four axes can be specified.
