6.COMPENSATION FUNCTION PROGRAMMING B-63944EN-2/02

- 216 -

compensation value is being changed, a movement by manual feed

can be made on one axis only.

When operation is stopped in the cutter compensation mode to make a

cutter compensation value change, a movable travel distance on one

axis is added, regardless of the direction of the compensation vector at

stop time.

Example

- Specified D code: H15

- Value set with offset number 15: 6.500mm

- Travel distance on the X-axis by manual feed:

2.379mm

- Travel distance on the Y-axis by manual feed:

-0.572mm

In this example, the value of offset number 15

becomes:

6.500+2.379+(-0.572)= 8.307mm

CAUTION

A cutter compensation value can be changed by a

movement on any linear axis. When an offset

value change for an axis is undesirable, interlock

the axis.

NOTE

A changed cutter compensation value is handled

according to bit 4 (EVR) of parameter No. 5001.

- Changing a workpiece origin offset value

The workpiece origin offset of the workpiece coordinate system

corresponding to a G code from G54 to G59 or from G54.1 P1 to P48

(300) specified during automatic operation is changed on an

axis-by-axis basis. A valid workpiece coordinate system exists at all

times. So, when a movement is made on an axis by manual feed, the

workpiece origin offset of the workpiece coordinate system is changed

without fail. This change can be made by a movement on an

arbitrary axis, which may be a linear axis or a rotation axis. While a

workpiece origin offset change is being made, movements can be

made on multiple axes by manual feed.
