B-63944EN-2/02 APPENDIX A.PARAMETERS

- 311 -

8371 Chopping reference point (point R)

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch, deg (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

The data set in this parameter is absolute coordinates.

8372 Chopping upper dead point

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch, deg (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

The data set in this parameter is absolute coordinates.

8373 Chopping lower dead point

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch, deg (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

The data set in this parameter is absolute coordinates.

8374 Chopping feedrate

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm/min, inch/min, deg/min (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] Refer to the standard parameter setting table (C)

(When the increment system is IS-B, 0.0 to +240000.0)

This parameter sets the chopping feedrate.
