B-63944EN-2/02 APPENDIX A.PARAMETERS

- 281 -

NOTE

During involute interpolation, the minimum

allowable feedrate of "clamping of acceleration

near a basic circle" in involute interpolation

automatic feedrate control is used.

1826 In-position width for each axis

[Input type] Parameter input

[Data type] 2-word axis

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

The in-position width is set for each axis.

When the deviation of the machine position from the specified

position (the absolute value of the positioning deviation) is smaller

than the in-position width, the machine is assumed to have reached the

specified position. (The machine is in the in-position state.)

#7 #6 #5 #4 #3 #2 #1 #0

3115 APLx

[Input type] Parameter input

[Data type] Bit axis

# 5 APLx When the active offset value modification mode based on manual feed

is selected, the relative position display is automatically:

0: Not preset.

1: Preset.

Use this parameter when returning a modified offset value to the

original value before modification in the active offset value

modification mode based on manual feed. The offset value can be

returned to the original value by making a movement on the axis by

manual feed so that the relative position display (counter) indicates the

position 0.

#7 #6 #5 #4 #3 #2 #1 #0

3290

GOF WOF

[Input type] Parameter input

[Data type] Bit path

# 0 WOF Setting the tool offset value (tool wear offset) by MDI key input is:

0: Not disabled

1: Disabled (With parameter No.3294 and No.3295, set the offset

number range in which updating the setting is to be disabled.)
