B-63944EN-2/02 APPENDIX A.PARAMETERS

- 299 -

#7 #6 #5 #4 #3 #2 #1 #0

5200

FHD PCP DOV G84

[Input type] Parameter input

[Data type] Bit path

# 0 G84 Method for specifying rigid tapping

0: An M code specifying the rigid tapping mode is specified prior to

the issue of the G84 (or G74) command. (See parameter

No.5210).

1: An M code specifying the rigid tapping mode is not used. (G84

cannot be used as a G code for the tapping cycle; G74 cannot be

used for the reverse tapping cycle.)

# 4 DOV Override during extraction in rigid tapping

0: Invalidated

1: Validated (The override value is set in parameter No.5211.

However, set an override value for rigid tapping return in

parameter No. 5381.)

# 5 PCP Rigid tapping

0: Used as a high-speed peck tapping cycle

1: Not used as a high-speed peck tapping cycle

# 6 FHD Feed hold and single block in rigid tapping

0: Invalidated

1: Validated

#7 #6 #5 #4 #3 #2 #1 #0

5201 OV3 OVU

[Input type] Parameter input

[Data type] Bit path

# 3 OVU The increment unit of the override parameter (No.5211) for tool rigid

tapping extraction is:

0: 1%

1: 10%

# 4 OV3 A spindle speed for extraction is programmed, so override for

extraction operation is:

0: Disabled.

1: Enabled.
