B-63944EN-2/02 APPENDIX A.PARAMETERS

- 307 -

6241

Feedrate during measurement of automatic tool length measurement (M

series) (for the XAE1 and GAE1 signals)

6242

Feedrate during measurement of automatic tool length measurement (M

series) (for the XAE2 and GAE2 signals)

6243

Feedrate during measurement of automatic tool length measurement (M

series) (for the XAE3 and GAE3 signals)

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm/min, inch/min, deg/min (machine unit)

[Minimum unit of data] Depend on the increment system of the applied axis

[Valid data range] Refer to the standard parameter setting table (C)

(When the increment system is IS-B, 0.0 to +240000.0)

These parameters set the relevant feedrate during measurement of

automatic tool compensation (T series) or automatic tool length

measurement (M series).

NOTE

When the setting of parameter No. 6242 or 6243 is

0, the setting of parameter No. 6241 is used.

6251

γ value during automatic tool length measurement (M series) (for the XAE1

and GAE1 signals)

6252

γ value during automatic tool length measurement (M series) (for the XAE2

and GAE2 signals)

6253

γ value during automatic tool length measurement (M series) (for the XAE3

and GAE3 signals)

[Input type] Parameter input

[Data type] 2-word path

[Unit of data] mm, inch, deg (machine unit)

[Minimum unit of data] Depend on the increment system of the applied axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

These parameters set the relevant γ value during automatic tool

compensation (T series) or automatic tool length measurement (M

series).
