B-63944EN-2/02 PROGRAMMING 6.COMPENSATION FUNCTION

- 217 -

Example

- Specified workpiece coordinate system : G56

- Workpiece origin offset of G56 (X axis) : 50.000

- Workpiece origin offset of G56 (Y axis) : -60.000

- Workpiece origin offset of G56 (Z axis) : 5.000

- Workpiece origin offset of G56 (A axis) : 5.000

- Workpiece origin offset of G56 (B axis) : 15.000

- Travel distance on the X axis by manual feed :

-10.000mm

- Travel distance on the Y axis by manual feed :

-5.000mm

- Travel distance on the Z axis by manual feed :

10.000mm

- Travel distance on the A axis by manual feed :

8.000mm

- Travel distance on the B axis by manual feed :

-2.000mm

In this example, the workpiece origin offsets of G56

are as follows:

- X axis : 50.000+(-10.000) = 40.000

- Y axis : -60.000+(-5.000) = -65.000

- Z axis : 5.000+10.000 = 15.000

- A axis : 5.000+8.000 = 13.000

- B axis : 15.000+(-2.000) = 13.000

- Operation depending on each tool offset memory

Offset value change operation varies according to tool offset memory

A/B/C as follows:

Tool offset

memory

Changed offset value

No distinction is made between a tool length compensation

value and cutter compensation value.

The value specified with the offset number corresponding to

the currently valid H code or D code is changed.

No distinction is made between a tool length compensation

value and cutter compensation value.

The value specified with the offset number corresponding to

the currently valid H code or D code is changed.

Depending on the setting of bit 4 (ASG) of parameter No.

5000, a geometry compensation value or wear compensation

value is changed.

The tool length compensation value and cutter compensation

value specified with the offset numbers corresponding to the

currently valid H code and D code are changed.

Depending on the setting of bit 4 (ASG) of parameter No.

5000, a geometry compensation value or wear compensation

value is changed.
