B-63944EN-2/02 APPENDIX A.PARAMETERS

- 305 -

# 3 INC If the M code for specifying negative direction rotation (parameter No.

No. 5511) is not set, the shortcut rotation direction in the G90 mode

is:

0: Not used.

1: Used.

# 4 G90 The command for the index table indexing axis:

0: Follows the absolute/incremental programming.

1: Is regarded as an absolute programming at all times.

5511 M code specifying negative direction rotation for index table indexing

[Input type] Parameter input

[Data type] 2-word path

[Valid data range] 0 to 99999999

0: The move direction of the index table indexing axis is determined

by bit 3 (INC) of parameter No. 5500 and the command.

1 to 99999999: The index table indexing axis moves in the positive

direction at all times. The index table indexing axis moves in the

negative direction only when an M code set with a move command is

specified.

NOTE

Be sure to set bit 2 (ABS) of parameter No. 5500 to

5512 Minimum positioning angle for the index table indexing axis

[Input type] Parameter input

[Data type] Real path

[Unit of data] Degree

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

Set a minimum positioning angle (angular displacement) for the index

table indexing axis. An angular displacement in a positioning

command must be an integral multiple of the setting of this parameter.

When 0 is set, no angular displacement is checked.

Not only commands but also coordinate system settings and

workpiece origin offset values are checked for a minimum positioning

angle.
