A.PARAMETERS APPENDIX B-63944EN-2/02

- 292 -

For inch input

OFE OFD OFC OFA Unit Valid data range

0 0 0 1 0.001inch ±999.999inch

0 0 0 0 0.0001inch ±999.9999inch

0 0 1 0 0.00001inch ±999.99999inch

0 1 0 0 0.000001inch ±999.999999inch

1 0 0 0 0.0000001inch ±99.9999999inch

#7 #6 #5 #4 #3 #2 #1 #0

5101

FXY

[Input type] Parameter input

[Data type] Bit path

# 0 FXY The drilling axis in the drilling canned cycle is:

0: Always the Z-axis

1: The axis selected by the program

NOTE

In the case of the T series, this parameter is valid

only for the drilling canned cycle in the Series 15

format.

#7 #6 #5 #4 #3 #2 #1 #0

5105

SBC

[Input type] Parameter input

[Data type] Bit path

# 0 SBC In a drilling canned cycle, chamfering, or corner R cycle:

0: A single block stop is not performed.

1: A single block stop is performed.
