A.PARAMETERS APPENDIX B-63944EN-2/02

- 310 -

7586

Rotation axis for fixture offset (third group)

7587

Linear axis 1 for fixture offset (third group)

7588

Linear axis 2 for fixture offset (third group)

[Input type] Parameter input

[Data type] Byte path

[Valid data range] 0 to Number of controlled axes

These parameters specify rotation axes for fixture offset and pairs of

linear axes for selecting a rotation plane. Specify a pair of linear axes

so that rotation from the positive direction of linear axis 1 to the

positive direction is in the normal direction of the rotation axis.

Up to three groups of a rotation axis setting and two linear axis

settings can be specified. The fixture offset value is calculated first for

the rotation axis in the first group. Then, for the second and third

groups, the fixture value is sequentially calculated using the previous

calculation result. When you do not need the third group, set 0 for the

rotation axis.

#7 #6 #5 #4 #3 #2 #1 #0

8360 ROV

[Input type] Parameter input

[Data type] Bit path

# 0 ROV As rapid traverse override for a section from the chopping start point

to point R:

0: Chopping override is used.

1: Rapid traverse override is used.

8370 Chopping axis

[Input type] Parameter input

[Data type] Byte path

[Valid data range] 1 to Number of controlled axes

This parameter sets which servo axis the chopping axis corresponds

to.
