6.COMPENSATION FUNCTION PROGRAMMING B-63944EN-2/02

- 102 -

- Tool length compensation B

G17 G43 Z_H_;

Shifts the coordinate system along the Z axis by the

compensation value, to the + side.

G17 G44 Z_H_;

Shifts the coordinate system along the Z axis by the

compensation value, to the - side.

G18 G43 Y_H_;

Shifts the coordinate system along the X axis by the

compensation value, to the + side.

G18 G44 Y_H_;

Shifts the coordinate system along the X axis by the

compensation value, to the - side.

G19 G43 X_H_;

Shifts the coordinate system along the Y axis by the

compensation value, to the + side.

G19 G44 X_H_;

Shifts the coordinate system along the Y axis by the

compensation value, to the - side.

G17 (or G18, G19) : Plane selection

G43 (or G44) : + (or -) side offset at which to start

tool length compensation

H_ : Address specifying the tool length

compensation value

- Tool length compensation C

G43 α_H_;

Shifts the coordinate system along a specified axis by the

compensation value, to the + side.

G44 α_H_;

Shifts the coordinate system along a specified axis by the

compensation value, to the - side.

G43 (or G44) : + (or -) side offset at which to start tool

length compensation

α_ : Address of any one axis

H_ : Address specifying the tool length

compensation value

- Tool length compensation cancel

G49; or H0; Tool length compensation cancel

G49 (or H0): Tool length compensation cancel
