B-63944EN-2/02 PROGRAMMING 7.MEMORY OPERATION USING Series 15 PROGRAM FORMAT

- 231 -

7 MEMORY OPERATION USING Series 15

PROGRAM FORMAT

Overview

Memory operation of the program registered in Series 15 program

format is possible by setting the setting parameter FCV (No. 0001#1)

to 1.

Explanation

Data formats for cutter compensation, subprogram call, and canned

cycles are different between the this CNC and Series 15. The Series

15 program formats can be processed for memory operation.

Other data formats must comply with the Series 30i. When a value

out of the specified range for the Series 30i is registered, an alarm

occurs. Functions not available in the Series 30i cannot be registered

or used for memory operation.

- Address for the cutter compensation offset number

Offset numbers are specified by address D in the Series 15.

When an offset number is specified by address D, the modal value

specified by address H is replaced with the offset number specified by

address D.

- Subprogram call

If a subprogram number of more than four digits is specified, the four

low-order digits are regarded as the subprogram number.

If no repeat count is specified, 1 is assumed.

Table 7 (a) Subprogram call program format

CNC Program format

Series 15

M98 P{{{{ L{{{{ ;

P : Subprogram number

L : Repetition count (1 to 9999)

Series 30

M98 P{{{

;

Repetition count Subprogram number

(1 to 9999)

- Address for the canned cycle repetition count for drilling

The Series 15 and this CNC use different addresses for the canned

cycle repetition count for drilling as listed in Table 7 (b).

Table 7 (b) Address for the canned cycle repetition count for drilling

CNC Address

Series 15 L

Series 30 K
