A.PARAMETERS APPENDIX B-63944EN-2/02

- 294 -

5148

Tool retraction direction after orientation in a fine boring cycle or back

boring cycle

[Input type] Parameter input

[Data type] Byte axis

[Valid data range] -10 to 10

This parameter sets an axis and direction for tool retraction after

spindle orientation in a fine boring cycle or back boring cycle. For

each boring axis, an axis and direction for tool retraction after

orientation can be set. Set a signed axis number.

Example)

Suppose that:

When the boring axis is the X-axis, the tool retraction direction after

orientation is -Y.

When the boring axis is the Y-axis, the tool retraction direction after

orientation is +Z.

When the boring axis is the Z-axis, the tool retraction direction after

orientation is -X.

Then, set the following (assuming that the first, second, and third axes

are the X-axis, Y-axis, and Z-axis, respectively):

Set -2 in the parameter for the first axis. (The tool retraction direction

is -Y.)

Set 3 in the parameter for the second axis. (The tool retraction

direction is -Y.)

Set -1 in the parameter for the third axis. (The tool retraction direction

is -X.)

Set 0 for other axes.

#7 #6 #5 #4 #3 #2 #1 #0

5160

NOL OLS

[Input type] Parameter input

[Data type] Bit path

#1 OLS When an overload torque detection signal is received in a peck drilling

cycle of a small diameter, the feedrate and spindle speed are:

0: Not changed.

1: Changed.

#2 NOL When the depth of cut per action is satisfied although no overload

torque detection signal is received in a peck drilling cycle of a small

diameter, the feedrate and spindle speed are:

0: Not changed.

1: Changed.
