B-63944EN-2/02 PROGRAMMING 5.FUNCTIONS TO SIMPLIFY PROGRAMMING

- 73 -

5.1.14 Canned Cycle Cancel for Drilling (G80)

G80 cancels canned cycles for drilling.

Format

G80 ;

Explanation

All canned cycles for drilling are canceled to perform normal

operation. Point R and point Z are cleared.

Other drilling data is also canceled (cleared).

Example

M3 S100 ; Cause the spindle to start rotating.

G90 G99 G88 X300. Y-250. Z-150. R-120. F120. ;

Position, drill hole 1, then return to point R.

Y-550. ; Position, drill hole 2, then return to point R.

Y-750. ; Position, drill hole 3, then return to point R.

X1000. ; Position, drill hole 4, then return to point R.

Y-550. ; Position, drill hole 5, then return to point R.

G98 Y-750. ; Position, drill hole 6, then return to the initial

level.

G80 G28 G91 X0 Y0 Z0 ; Return to the reference position, canned cycle

cancel

M5 ; Cause the spindle to stop rotating.
