5.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63944EN-2/02

- 48 -

- Tool length compensation

When a tool length compensation (G43, G44, or G49) is specified in

the canned cycle for drilling, the offset is applied after the time of

positioning to point R.

Limitation

- Axis switching

Before the drilling axis can be changed, the canned cycle for drilling

must be canceled.

- Drilling

In a block that does not contain X, Y, Z, R, or any additional axes,

drilling is not performed.

- P/Q

Be sure to specify a positive value in Q. If Q is specified with a

negative value, the sign is ignored. Set the direction of shift in the

parameter (No.5148).

Specify P and Q in a block that performs drilling. If they are

specified in a block that does not perform drilling, they are not stored

as modal data.

CAUTION

Q (shift at the bottom of a hole) is a modal value

retained within canned cycles for drilling. It must

be specified carefully because it is also used as the

depth of cut for G73 and G83.

- Cancel

Do not specify a G code of the 01 group (G00 to G03) and G76 in a

single block. Otherwise, G76 will be canceled.

- Tool offset

In the canned cycle mode for drilling, tool offsets are ignored.

Example

M3 S500 ; Cause the spindle to start rotating.

G90 G99 G76 X300. Y-250.

Position, bore hole 1, then return to point R.

Z-150. R-120. Q5. Orient at the bottom of the hole, then shift by 5

mm.

P1000 F120. ; Stop at the bottom of the hole for 1 s.

Y-550. ; Position, drill hole 2, then return to point R.

Y-750. ; Position, drill hole 3, then return to point R.

X1000. ; Position, drill hole 4, then return to point R.

Y-550. ; Position, drill hole 5, then return to point R.

G98 Y-750. ; Position, drill hole 6, then return to the initial level.

G80 G28 G91 X0 Y0 Z0 ; Return to the reference position

M5 ; Cause the spindle to stop rotating.
