B–63002EN/01

9. SPINDLE FUNCTIONS

NC FUNCTION

103

In turning operation, the spindle connected to the spindle motor rotates

at a certain speed, and the workpiece attached to the spindle is then turned.

The spindle positioning function moves the spindle connected to the

spindle motor by a given angle so that the workpiece attached to the

spindle is positioned at a desired angle.

With this function, any portion of the workpiece can be drilled.

The spindle position is detected by the position corder attached to the

spindle.

Whether to use the spindle for spindle positioning (spindle positioning

mode) or to use the spindle for spindle rotation (spindle rotation mode)

is command by special M code (set by parameters).

 Move command

When commanded:

G00 C_ ;,

The spindle is positioned to the commanded position by rapid

traverse. Absolute (G90) and incremental (G91) command, as well

as decimal point input is possible.

 Increment system

Least input increment: 0.001 deg.

Detection unit: (360×N)/4096 deg.

N: Combination ratio of position coder and spindle (N=1, 2, 4)

9.8

SPINDLE

POSITIONING

(T series)

T series
