Series 16/18/21/20/160/180/210i Descriptions Page 36

Descriptions

Page of 536

/ 536

B–63002EN/01

2. LIST OF SPECIFICATIONS

GENERAL

Item Specifications

Series 16i

Series 160i

Series 18i

Series 180i

Series 21i

Series 210i

MA TA MA TA MA TA

Optional–angle chamfering/corner

rounding

 —

 —  —

Programmable data input G10  

   

Subprogram call 4 levels of nesting  

   

Custom macro B  

   

Addition to custom macro common

variables

#100 to #199, #500 to #999  

   

Macro variables common to 2 paths For 2–path system  

—  — —

Pattern data input *1  

   

Interrupt–type custom macro  

   

Canned cycle — 

—  — 

Multiple repetitive canned cycle — 

—  — 

Multiple repetitive canned cycle II Pocket profile — 

—  — 

Canned cycle for drilling  

   

Small–diameter peck drilling cycle  —

 —  —

Canned cycle for grinding For grinder  

  — —

Arc radius R programming  

   

Arc radius R programming with 9

digits

— 

—  — —

Mirror image of facing tool posts — 

—  — 

Automatic corner override  

   —

Automatic corner deceleration  —

 — — —

Feedrate clamp by arc radius  —

 —  —

Scaling  —

 —  —

Coordinate system rotation  

   —

Three–dimensional coordinate con-

version

 

  — —

Programmable mirror image  —

 —  —

Figure copy  —

 — — —

Retrace  —

 — — —

Series 15 tape format  

  — —

Series 10/11 tape format — —

— —  

Conversational programming

For single–path system only

 

  — —

Macro executor

Up to 1MB *1 — —

— —  

acro execu

Up to 4MB *1  

  — —

C macro executor Up to 4MB *1  

  — —

Note) *1 For the Series 16i, 18i, and 21i only

*2 For the Series 160i, 180i, and 210i only
