B–63002EN/01

5. FEED FUNCTIONS

NC FUNCTION

With the G04 command, shifting to the next block can be delayed.

When commanded with a per minute feed mode (G94), shifting to the next

block can be delayed for the commanded minutes.

When commanded with a per rotation feed mode (G95), shifting to the

next block can be delayed till the spindle rotates for the commanded

times.

Dwell may always be performed by time irrespective of G94 and G95 by

parameter selection.

G94 G04

;

G95 G04

;

P_ or X_ : Spindle rotation angle commanded in rev.

(0.001-99999.999 rev)

Per second dwell

P_ or X_ : Dwell time commanded in seconds (0.001-99999.999 sec)

Per revolution dwell

When a rapid traverse command is specified during automatic operation,

the function for positioning by optimum acceleration can be used to adjust

the rapid traverse rate, time constant, and loop gain, according to the

amount of travel for the block. This reduces the time required for

positioning and position check, therefore reducing the cycle time.

When rapid traverse is specified in automatic operation, the function

adjusts the rapid traverse rate, time constant, and loop gain to one of seven

levels, according to the amount of travel for the block. The relationship

between the amount of travel and the corresponding rapid traverse rate,

time constant, and loop gain is specified in parameters. This function is

not effective for cutting feed.

5.15

DWELL (G04)

Format

5.16

POSITIONING BY

OPTIMUM

ACCELERATION
