35. PERSONAL COMPUTER

FUNCTION

B–63002EN/01

NC FUNCTION

354

The CNC’s built–in personal computer function has the following

features:

 High compatibility with the IBM PC(*1)

 Windows 95 operating system, which supports many software

products for the IBM PC(*1)

 Optional ISA expansion unit, enabling the installation of

commercially available expansion boards (ISA specification) for the

IBM PC(*1)

 Installation combined with the CNC

 Direct connection to the CNC via a bus, enabling the high–speed

exchange of a wide range of information

 Highly reliable design based on design technologies realized through

the development of CNCs

CNC function + personal computer function board

CNC main body

Personal computer software for open CNC

Item

Specification Remarks

Operating system Windows95

Dedicated drivers

NC program memory driver

NC data file driver

Optional

Dedicated library CNC/PMC data window

Package software

CNC maintenance package

Package

software

CNC basic operation package Optional

Development tools

Visual C ++ *1

Visual Basic *1

Microsoft Corporation

35.1

BUILT–IN PERSONAL

COMPUTER

FUNCTION
