11. MISCELLANEOUS FUNCTIONS

B–63002EN/01

NC FUNCTION

114

When up to eight digits immediately after address M are specified, a

32–bit binary code is output. The maximum number of input digits can

be specified with a parameter. This binary code is used for on/off control

of the machine. A block can usually contain up to three M codes although

only one of them is effective.

The following M codes are used for special purposes:

M00 : Program stop

M01 : Optional stop

M02 : End of program

M30 : End of program and tape rewind

The above M codes can also be output in binary codes.

M98 (sub program call) and M99 (return from sub program) and always

processed in the CNC so, signal will not be output.

Up to three M codes can be simultaneously specified in one block.

As these M codes are simultaneously sent to PMC side, the machining

cycle time compared with the conventional 1-block single M command

is reduced.

Example)

(i) 1-block single M command

M40;

M50;

M60;

G28G91X0Y0Z0;

(ii) 1-block plural M command

M40M50M60;

G28G91X0Y0Z0;

NOTE

1 The maximum input value of the first M code is 99999999,

while the maximum input values of the second and third M

codes are 65535.

2 A strobe signal is provided for each of the first to third M

codes (MF, MF2, and MF3).

When all the operations for the first to third M codes are

completed, completion signal FIN is output.

When an 8-digit number after address B is commanded, a 32-bit binary

code is output to the PMC. This code is kept till the next B code is

commanded.

11.1

MISCELLANEOUS

FUNCTIONS

11.2

1–BLOCK PLURAL M

COMMAND

11.3

SECOND

MISCELLANEOUS

FUNCTIONS
