Series 16/18/21/20/160/180/210i Descriptions Page 397

Descriptions

Page of 536

/ 536

B–63002EN/01

2. CONVERSATIONAL AUTOMATIC

PROGRAMMING FUNCTION FOR

LATHES

AUTOMATIC PROGRAMMING

FUNCTION

376

 Symbolic input

 CAD input

 CAD data input (DXF)

Symbolic CAP T can automatically determine the following machining

types. It also supports manual selection.

 Basic module/2–path control module

 Center hole machining (center drilling, drilling, reaming, tapping)

 Roughing (outer, inner, or end surface) (normal or reverse tool)

 Semi–finishing (outer, inner, or end surface) (normal or reverse

tool)

 Finishing (outer, inner, or end surface) (normal or reverse tool)

 Rough grooving (outer, inner, or end surface)

 Finish grooving (outer, inner, or end surface)

 Rough/finish grooving (outer, inner, or end surface)

 Threading (outer, inner, or front surface)

 C–/Y–axis module

 Milling and hole machining using the C– and Y–axes

2.3.3

Conversational

Automatic

Programming

Function

Figure input

Machining type
