FANUC Series 16i/18i/21i/160i/180i/210i-MODEL B

CONNECTION MANUAL (FUNCTION)

Concerning the addition of

Interpolation type straightness compensation

B-63523EN-1

01-4

01 01.09.17 Newl

istered

FANUC Series 16i/18i/21i/160i/180i/210i-MODEL B

CONNECTION MANUAL (FUNCTION)

Concerning the addition of Interpolation type straightness compensation

1.Type of applied technical documents

Name

FANUC Series 16i/18i/21i/160i/180i/210i-MODEL B

CONNECTION MANUAL (FUNCTION)

Spec.No./Ed. B-63523EN-1/01

2.Summary of Change

Group Name/Outline

New, Add,

Correct,

Delete

Applicable

Date

Basic

Optional

Function

Interpolation type straightness compensation

After 1.3.8 About Difference among Pitch Error

Compensation, Straightness Compensation, and

Gradient Compensation (for Reference Purposes),

the following item is added.

1.3.9 Interpolation type straightness compensation

Add Immediately

Unit

Maintenance

Parts

Notice

Stored pitch error compensation option is needed for this function

Correction

Another

This function is available in the following software.

FS16i–TB : B1H1/03 or later FS16i–MB : B0H1/02 or later

FS18i–TB : BEH1/03 or later FS18i–MB : BDH1/02 or later
