Series 16/18/21/20/160/180/210i Descriptions Page 530

Descriptions

Page of 536

/ 536

8/11

PAGEEDT.

DATE

DESIGN

DESCRIPTION

TITLE

No.

FANUC Series 16i/18i/21i/160i/180i/210i-MODEL B

CONNECTION MANUAL (FUNCTION)

Concerning the addition of

Interpolation type straightness compensation

B-63523EN-1

/

01-4

01 01.09.17 Newl

y

Re

g

istered

Parameter

5711 Axis number of moving axis 1

5712 Axis number of moving axis 2

5713 Axis number of moving axis 3

5714 Axis number of moving axis 4

5715 Axis number of moving axis 5

5716 Axis number of moving axis 6

[Data type] Byte type

[Valid data range] 1 – Number of controlled axes

Set the axis number of moving axes.

5721 Axis number of compensation axis 1 for moving axis 1

5722 Axis number of compensation axis 2 for moving axis 2

5723 Axis number of compensation axis 3 for moving axis 3

5724 Axis number of compensation axis 4 for moving axis 4

5725 Axis number of compensation axis 5 for moving axis 5

5726 Axis number of compensation axis 6 for moving axis 6

[Data type] Byte type

[Valid data range] 1 – Number of controlled axes

Set the axis number of compensation axes.

13381

Number of straightness compensation point at extremely negative

point of moving axis 1

13382

Number of straightness compensation point at extremely negative

point of moving axis 2

13383

Number of straightness compensation point at extremely negative

point of moving axis 3

13384

Number of straightness compensation point at extremely negative

point of moving axis 4

13385

Number of straightness compensation point at extremely negative

point of moving axis 5
