Series 16/18/21/20/160/180/210i Descriptions Page 500

Descriptions

Page of 536

/ 536

7/9

PAGEEDT.

DATE

DESIGN

DESCRIPTION

TITLE

No.

FANUC Series 16i/18i/21i/20i/160i/180i/210i-MODEL A

CONNECTION MANUAL (FUNCTION)

Concerning the addition of Look-Ahead Bell-Shaped

Acceleration/Deceleration Before Interpolation Time

Constant Change Function

B-63003EN-1

02-08 01 01.08.29 Newl

istered

(2) A proper acceleration is determined under the condition

that the acceleration change must be about the same as

the setting so that parameter changes do not cause

considerable shock to the machine, that is:

change before

timechangeon Accelerati

change beforeon Accelerati

changeafter

timechangeon Accelerati

changeafter on Accelerati

The acceleration change time is regarded to be the sum of

the acceleration change time of bell-shaped

acceleration/deceleration and the time constant of

acceleration/deceleration after interpolation, and the

acceleration A' for the acceleration/deceleration before

interpolation is determined as follows:

TcT

∗=

A: Acceleration for the acceleration/deceleration before

interpolation

Tc : Time constant of acceleration/deceleration after

interpolation

Acceleration/deceleration is performed using T2' and A',

determined as described above.

Parameters

#7 #6 #5 #4 #3 #2 #1 #0

7055 BCG

[Input section] Parameter input

[Data type] Bit type

# 3 BCG The bell-shaped acceleration/deceleration time constant change function in

AI Contour control mode or AI Nano contour control mode is:

0: Disabled.

1: Enabled.

In AI High Precision Contour control mode or AI Nano High Precision

Contour control mode, parameter BCG (No.19501#6) should be set.
