B–63002EN/01

2. CONVERSATIONAL AUTOMATIC

PROGRAMMING FUNCTION FOR

LATHES

AUTOMATIC PROGRAMMING

FUNCTION

361

CAP II is a conversational automatic programming function for lathes.

It has the following features:

 Part figures can be input in a batch by using the symbolic keys.

 Even complicated part figures can be input by using the automatic

intersection calculation function.

 The automatic process determination function creates necessary

processes automatically.

 Any cutting direction or area can be specified.

 NC data can be created without superfluous movement, such as cutting

through air.

 By using MTF, NC data suitable for the particular machine being used

can be created.

CAP II can be used with the following lathes:

 1–spindle/1–turret lathe

 1–spindle/2–turret lathe

 2–spindle (main spindle and sub spindle)/1–turret lathe

 Lathe with Y–axis/C–axis machining functions

 Lathe with chasing tool

 Vertical lathe

2.1

CONVERSATIONAL

AUTOMATIC

PROGRAMMING

FUNCTION II (CAP II)

2.1.1

Features

2.1.2

Applicable Machines
