Series 16/18/21/20/160/180/210i Descriptions Page 232

Descriptions

Page of 536

/ 536

17. MEASUREMENT FUNCTIONS

B–63002EN/01

NC FUNCTION

210

 Setting of tool compensation value

Previously set the distance from the measurement reference position

(a particular point on the machine) to the measuring position (the touch

sensor contact face) to the parameter as the reference value.

As the tool of which the offset amount is to be measured is selected and

is positioned at the measuring position (contact the touch sensor), the

contact detection signal (tool compensation value write signal) from

the touch sensor is received, and the difference between the machine

coordinate value at that time (= the distance from the measured tool

nose tip position at the machine reference position (machine zero

point) to the measuring position) and the reference value (parameter

value) is set in the tool offset amount memory as the tool geometry

offset amount of that tool. The corresponding tool wear offset amount

becomes zero.

Tool offset

amount to

be set

Machine coordi-

nate value when

tool compensa-

tion value write

signal turns “1”

Reference value

(value of parameter)

corresponding to

tool compensation

value write signal

The tool offset amount to be set depends on how to determine the

measurement reference position.

 Setting of work coordinate system shift amount

The work coordinate system shift amount along the Z axis is to be set

as follows. When the tool touches the end face of the workpiece, the

touch detection signal (workpiece coordinate system shift write

signal) is output. This signal is used to set the workpiece coordinate

system shift, calculated by subtracting the tool geometry

compensation value (shift of coordinate system due to tool geometry

compensation) from the current machine coordinate (distance between

the end face of the workpiece and the tip of the measurement tool when

it is at the machine reference position (machine zero point)). In this

case the tool geometry offset amount corresponding to the tool must

be programmed previously.

Machine

coordinate value

of Z axis (Zt)

Work coordinate

system shift amount

along Z axis to be

set (EXOFSz)

Tool geometry offset

amount of Z axis of

corresponding tool

(OFSz)

By the above procedure the work coordinate system with the work edge

(sensor contact point) being taken as the work coordinate system zero

point of the Z axis (the program zero point) is set when the tool is selected

by the program command (T code).

 Setting method
