11. MISCELLANEOUS FUNCTIONS

B–63002EN/01

NC FUNCTION

116

NOTE

1 Either the conventional system or the high-speed system

can be selected for communication of strobe signal and

completion signal.

2 In the conventional system, only one completion signal is

available for all functions of M/S/T/B. However, in the high-

speed system, one completion signal is available for each

of M/S/T/B functions.

The M code group check function checks if a combination of multiple M

codes (up to three M codes) contained in a block is correct.

This function has two purpose. One is to detect if any of the multiple M

codes specified in a block include an M code that must be specified alone.

The other purpose is to detect if any of the multiple M codes specified in

a block include M codes that belong to the same group.

11.5

M CODE GROUP

CHECK FUNCTION
