23. MANUAL OPERATION

NC FUNCTION

263

 Jogging

Each axis can be moved in the + or - direction for the time the button

is pressed. Feed rate is the parameter set speed with override of:

0 - 655.34%, 0.01% step.

The parameter set speed can be set to each axis.

 Manual rapid feed

Each axis can be fed in a rapid feed to the + or - direction for the time

the button is pressed.

Rapid traverse override is also possible.

Specified move amount can be positioned to the + or - direction with the

button.

Move amount of:

(least command increment) x (magnification)

can be specified. The feed rate is that of manual feed.

The possible magnifications to be specified are as follows.

×1, ×10, ×100, ×1000.

Increment system Metric input Inch input

IS–B 0.001, 0.01, 0.1, 1.0 0.0001, 0.001, 0.01, 0.1

IS–C 0.0001, 0.001, 0.01, 0.1 0.00001, 0.0001, 0.001, 0.01

By rotating the manual pulse generator, the axis can be moved for the

equivalent distance. Manual handle feed is controlled 1 axis at a time.

The manual pulse generator generates 100 pulses per rotation. Move

amount per pulse can be specified from the following magnifications:

×1, ×10, ×M, ×N.

N is parameter set values of 0 - 1000. M is parameter set values of 1–127.

Move distance is :

(Least command increment) x (magnification)

Increment system Metric input Inch input

IS–B 0.001, 0.01, M/1000,

N/1000 mm

0.0001, 0.001, M/10000,

N/10000 inch

IS–C 0.0001, 0.001, M/10000,

N/1000 mm

0.00001, 0.0001, M/100000,

N/100000 inch

A 2nd, as well as 3rd manual pulse generator can be rotated to move the

axis for the equivalent distance. Manual handle feed of 3 axes (for T

system, 2 axes) can be done at a time. Multiplier is common to 1st, 2nd

and 3rd manual pulse generators.

23.1

MANUAL FEED

23.2

INCREMENTAL FEED

23.3

MANUAL HANDLE

FEED (1ST)

23.4

MANUAL HANDLE

FEED (2ND, 3RD)

(T SERIES: 2ND)
