Series 16/18/21/20/160/180/210i Descriptions Page 48

Descriptions
1. CONTROLLED AXES
B–63002EN/01
NC FUNCTION
26
Two–path control is available in 16i–MA, 16i–TA, and 18i–TA,
160i–MA, 160i–TA, 180i–TA
In 18i–MA, 180i–MA, 21i–MA, 21i–TA, 210i–MA, 210i–TA number of
controlled paths is one.
16i–MA/18i–MA/160i–MA/180i–MA/21i–MA/210i–MA (each path) :
3 axes
16i–TA/18i–TA/160i–TA/180i–TA/210i–TA/210i–MA (each path) :
2 axes
16i–MA/18i–MA/160i–MA/180i–MA/21i–MA/210i–MA (each path) :
3 axes
16i–TA/18i–TA/160i–TA/180i–TA/21i–TA/210i–TA (each path) :
2 axes
16i–MA/16i–TA/160i–MA/160i–TA (1–path) :
Max. 8 axes (including Cs axis)
16i–MA/16i–TA/160i–MA/160i–TA (2–path) :
Max. 7 axes (6 feed axes + Cs axis)
18i–MA/18i–TA/180i–MA/180i–TA (1–path) :
Max. 6 axes (including Cs axis)
18i–TA/180i–TA (2–path) :
Max. 5 axes (4 feed axes + Cs axis)
21i–MA/21i–TA/210i–MA/210i–TA :
Max. 4 axes (including Cs axis)
16i–MA/16i–TA/160i–MA/160i–TA (each path) : Max. 6 axes
18i–MA/18i–TA/180i–MA/180i–TA (each path) : Max. 4 axes
21i–MA/21i–TA/210i–MA/210i–TA : Max. 4 axes
16i–MA/16i–TA/18i–MA/18i–TA/21i–MA/21i–TA/160i–MA/160i–
TA/180i–MA/180i–TA/210i–MA/210i–TA (each path) :
Max. simultaneous 4 axes (Cs axis is disable.)
16i–MA/16i–TA/18i–MA/18i–TA/21i–MA/21i–TA/160i–MA/160i–
TA/180i–MA/180i–TA/210i–MA/210i–TA (each path) :
1 axis
1.2
MACHINE
CONTROLLED AXES
1.2.1
Number of Controlled
Paths (T series)
1.2.2
Number of Basic
Controlled Axes
1.2.3
Number of Basic
Simultaneously
Controlled Axes
1.2.4
Number of Controlled
Axes Expanded (All)
1.2.5
Number of
Simultaneously
Controlled Axes
Expanded (All)
1.2.6
Axis Control by PMA
1.2.7
Cs Contour Control
