Series 16/18/21/20/160/180/210i Descriptions Page 33

Descriptions
B–63002EN/01
2. LIST OF SPECIFICATIONS
GENERAL
9
Item Specifications
Series 16i
Series 160i
Series 18i
Series 180i
Series 21i
Series 210i
p
MA TA MA TA MA TA
Handle feed in tool axis direction B
(Tool axis direction) +
(Vertical direction)
—
— — —
Manual handle interrupt
Incremental feed 1, 10, 100, 1000
Jogging/handle feed mode
Manual numeric command *1
— —
Manual linear/circular interpolation For single–path system only
— —
Interpolation functions
Positioning
G00 (Linear interpolation type
positioning enabled)
Unidirectional positioning G60 —
— —
Exact stop mode G61 —
— —
Exact stop G09 —
— —
Linear interpolation
Circular interpolation
Supported for multiple quad-
rants
Exponential interpolation —
— — —
Dwell
For a specified number of se-
conds or rotations (To specify
dwell for a specified number of
rotations for MA, the thread-
ing/synchronous feed function
is necessary.)
Polar coordinate interpolation
—
Cylindrical interpolation
Helical interpolation
(Circular interpolation) +
(Linear interpolation for up to 2
axes)
—
Helical interpolation B
(Circular interpolation) +
(Linear interpolation for up to 4
axes)
—
— — — —
Involute interpolation —
— — —
Hypothetical axis interpolation
— —
Spiral/conical interpolation —
— — —
Smooth interpolation
High–precision contour control
function required
—
— — — —
Threading/synchronous feed
Multi–start threading —
— —
Threading retract —
— —
Continuous threading —
— —
Variable–lead threading —
— —
Circular threading —
— — —
Polygon turning —
— —
Polygon turning between spindles —
— — —
Skip G31
High–speed skip
Continuous high–speed skip —
— — —
Multi–step skip
—
Torque–limit skip —
— —
Reference position return G28
Note) *1 For the Series 16i, 18i, and 21i only
*2 For the Series 160i, 180i, and 210i only
