27. DISPLAYING AND SETTING DATA

NC FUNCTION

319

The periodic maintenance screen shows the current statuses of those

consumables that require periodic replacement (backup battery, LCD

backlight, touch pad, etc.). An item whose service life has expired is

indicated by the machine run time or the like.

PERIODICAL MAINTENANCE O0001 N12345

(STATUS)

ITEM NAME REMAIN

01 BATTERY FOR CONTROLLER 0H

@ 02 BATTERY FOR PULSECODER 5000H

03 LCD BACK LIGHT 10000H

@ 04 COOLANT 720H

EDIT **** *** *** 19:27:05

[ ][MAINTE ][ ][ ][(OPRT) ]

A pen input device/touch pad, manufactured by Fujitsu Limited, is used

on the LCD display as follows:

(1)The soft keys below the 10.4–inch color LCD/MDI panel (F0 to F9,

FR, and FL) are replaced by the soft keys on the touch pad.

(2)The cursor displayed on the 10.4–inch color LCD is controlled from

the touch pad.

(3)A touch–pad–type software machine operator’s panel, realized by C

executor, can be used.

(4)A touch–pad–type calculator, realized by C executor, can be used.

(5)A C executor application program can be created by using the touch

pad.

The history of the maintenance carried out by FANUC service personnel

and machine tool builder can be recorded via the screen. The screen has

the following features:

 Alphabetical characters can be input from MDI. (Half–size kana can

be input only when Japanese display is selected.)

 The recording screen can be scrolled, line by line.

 Edited maintenance information can be read and punched.

 Data can be stored into flash ROM.

 Full–size (shift JIS) codes can be displayed. (Input codes are read

only.)

27.18

PERIODIC

MAINTENANCE

SCREEN

27.19

TOUCH PAD

27.20

MAINTENANCE

INFORMATION

SCREEN
