B–63002EN/01

19. SERIES 15 TAPE FORMAT/

SERIES 10/11 TAPE FORMAT

NC FUNCTION

225

The programs for the following functions can be created in the Series

10/11 tape format, and be executed by the setting parameter, using the

memory.

 Equal lead threading (G33) (T series): (G32 for G-code system A)

 Sub program calling (M98)

 Canned cycles (G77, G78, G79) (T series):

(G90, G92, G94 for G-code system A)

 Multiple repetitive canned cycles (G71 to G76) (T series)

 Canned cycles for drilling (G80 to G85) (T series)

 Canned cycles (G73, G74, G76, G80 to G89) (M series)

NOTE

Addresses and range of values to be specified the Series

16/18 format restrictions are placed on the range of

specifiable values of the basic address. Specifying a value

outside the Series 16/18 format range causes a P/S alarm.

The restrictions are placed also on some addresses.

Memory operation of a program created for the following function in the

Series 10/11 tape format can be performed based on the setting parameter.

 Equal–lead threading (G33) (T series) ... (G32 with G code system A)

 Subprogram call (M98)

 Canned cycle (G77, G78, G79) (T series) ... (G90, G92, and G94 with

G code system A)

 Multiple repetitive canned cycle (G71 to G76) (T series)

 Canned cycle for drilling (G80 to G85) (T series)

 Canned cycle (G73, G74, G76, G80 to G89) (M series)

NOTE

Address and value specification range

The restrictions imposed on the Series 21 format are also

imposed on the value specification range for the basic

addresses. When a specified value exceeds the range of

the Series 21 format, a P/S alarm is issued. The use of

addresses may be restricted in some cases.

19.1

SERIES 15 TAPE

FORMAT

19.2

SERIES–10/11 TAPE

FORMAT
