Series 16/18/21/20/160/180/210i Descriptions Page 133

Descriptions

Page of 536

/ 536

B–63002EN/01

10. TOOL FUNCTIONS

NC FUNCTION

111

Tools are classified into groups, and tool life (hours and times of use) is

set for each group. When use of the tool exceeds the preset hours or times

of use, another tool in the same group which has not yet exceeded the

preset life time is selected. If all the tool in a group exceeds the preset

life time, a signal is output to inform the operator that the tools must be

changed to new tools. With setting the cutter radius compensation

number and the tool length compensation number of the tools,

compensation corresponding to each tool can also be done. (M series)

With use of this function Factory Automation (FA) comes to a reach.

This function has the following features:

 Tool life can be set in hours or times of use.

 New tool select signal output

This signal is output when a new tool is selected in a group. This can

also be used for automatic measurement in compensations of the new

tools.

 Tool change signal

When all the tools of a group has exceeded their life time, this signal

is output to inform the operator.

 Tool skip signal

By inputting this signal, tools still not exceeding their life time, can

also be changed.

 Tool life management data is display/modification

Tool life management data is displayed on the cRT screen, informing

the operator of the condition of the tools at a single view. If necessary,

the counter value of tool life can be modified via the MDI panel.

Number of groups and number of tools per group is selected by

parameter from the following.

M series T series

Number of

groups

Number of tools

Number of

groups

Number of tools

16 16 16 16

32 8 32 8

64 4 64 4

128 2 _____ _____

10.2

TOOL LIFE

MANAGEMENT

10.2.1

Tool Life Management
