15.

CUSTOM

MACRO

G65P9011AlOM;

Calls custom macro

body 9011 and sets

variables

and

tolOand5

respectively.

used instead of the

unknown

traverse distance.

Fig.1 5 (b)

Custom macro instruction and variables

This means that a function of general use can be formed when programming a certain

function as a custom macro. That is, programs can be written using variables for data

that might change or be unknown. This can be further applied to group technology.

Similar workpieces can be collected as a group and a universal custom macro body

can be programmed using variables applicable to each group. In this way,

programming is not required for the workpieces in the group. The programmer only

need to assign actual values to the variables.

Bolt hole circles as shown in the above figure can be made easily.

Once a custom macro body for the bolt hole circle is programmed and registered, the

CNC can operate as if it has the bolt hole circle cutting function.

Programmers can use the bolt hole circle function by using the following command

only: __

(Example of calling bolt hole circle)

G65P

K k

;

Macro number of bolt hole circle

Radius

Start angle

Angle between circles

Number of circles
