Power Mate D and F Motion Controllers Programming manual Page 99

Programming manual

Page of 373

/ 373

15.

15.1

CUSTOM MACRO

Macro

CaJi

Command (Custom Macro Command)

When these M codes are specified in a macro called with a G code or in a

subprogram called with an M code or a T code, the subprogram is not called, but

these M codes are treated as ordinary

codes. Set parameters

6071

6073.

15.1.6

Subprogram call with

code

If parameter TCS (No.

6OOW5)

is set to 1 in advance, a subprogram can be called

with a T

code.

N G X Z

T t;

isequiva=o

the following two blocks.

#149=t;

N G X Z

---

M98

P9000;

Tcode t is stored as an argument in common variable

#149.

The T code is displayed

on the program check screen, but TF and T codes are not transmitted.

When this T code is specified in a macro called with a G code, or in a subprogram

called with an M or T code, the subprogram is not called; but this T code is treated as

ordinary T code.

15.1.7

Difference between M98 (subprogram call) and

G65

(custom macro body call)

(

15.1.8

Multiplex

calls

(1)

Multiplex calls

G65

can include arguments; M98 cannot.

M98 is used to branch to a subprogram after executing a command other than

M or P in the block;

G65

is used to branch only.

When a M98 block includes an address other than 0, N and P, execution of the

block stops as single block stop, a

G65

block does not stop as single block

stop.

G65

changes the level of local variable; M98 does not. That is,

specified

before G65 is one thing and

in the calling custom macro body is another.

specified before M98 is the same as

in the calling subprogram.

Up to four

G65

calls, including G66, can be made in addition, M98 calls can be

made up to four calls.

Similarly to a subprogram called from another subprogram, a macro can be

called from another macro.

The multiplicity should be less than or equal to four including simple and modal

calls.

-Multiplex modal calls

In modal calls, the specified macro is called each time a motion command is

executed. When several modal macros are specified, the next macro is called

each time a motion command in the first macro is executed.

Macros are

successively called from those assigned later.

(Example 1)

G66

P9100;

z 1000.0; (l-l)

1-76
