FANUC Series 16i /18i Additional Manual Page 139

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
139/190
#7 #6 #5 #4 #3 #2 #1 #0
8414 RRD
[Data type] Bit
RRD In the axis of the diameter programming, the program instruction in the AI
HPCC / AI NANO HPCC mode is:
0: Radius programming
1: Diameter programming
Note
In setting this parameter to “1”, the moving amount in AI HPCC mode and AI NANO
APCC mode is twice when the program made subject to the diameter programming
is executed.
#7 #6 #5 #4 #3 #2 #1 #0
8411 RDM RDR RDA
[Data type] Bit
RDM When a parameter No.8414#0(RRD) is “1”, the display of the machine coordinate
system of the actual position display is:
0: displayed by the diameter value.
1: displayed by the radius value.
RDR When a parameter No.8414#0(RRD) is “1”, the display of the relative coordinate
system of the actual position display is:
0: displayed by the diameter value.
1: displayed by the radius value.
RDA When a parameter No.8414#0(RRD) is “1”, the display of the absolute coordinate
system and distance to go of the actual position display are:
0: displayed by the diameter value.
1: displayed by the radius value.
3.3 Auxiliary Function
#7 #6 #5 #4 #3 #2 #1 #0
8403 MSU
[Data type] Bit
MSU When M, S, or B code is specified in AI HPCC / AI NANO HPCC mode:
0: An alarm occurs.
1: The CNC executes the command.
