FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
29/190
(3) Notes concerning scaling and each axis scaling
• Scaling and each axis scaling
• Instruction form
• Position display
• Magnification
• Manual operation
• Move amount
• Absolute and incremental
Note
When the each axis scaling is effective, all axis common magnification of P
command cannot be used. Scaling is not executed by P command.
Note
Specify G50 and G51 in a separate block. Please cancel with G50 when scaling
becomes unnecessary.
Note
The position display represents the coordinate value after scaling.
Note
1. If a parameter setting value is used as a scaling magnification without
specifying P etc., the value when G51 is commanded is used as the scaling
magnification. Therefore, even if changing the parameter, the value is not
effective soon.
2. The decimal point cannot be input to magnification I, J, and K
Note
Scaling is effective only to the automatic operation. It is not effective in the manual
o
p
eration.
Note
If scaling results are rounded off, the move amount may become zero. In this
case, the block is regarded as a no movement block, and therefore, it may affect
the tool movement by the cutter compensation C.
Note
It is assumed that the scaling center is not specified for an incremental command
until the absolute position command appears after the G51 mode turns on. (That
is, the position of the instruction in G51 becomes a scaling center)
