FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
176/190
19524 Ratio of the jerk change time in smooth bell-shaped acceleration/deceleration
before interpolation
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 50
Specify the percent jerk change time with respect to the acceleration change time
(*1) in look-ahead smooth bell-shaped acceleration/ deceleration.
If this parameter is 0 or out of the valid data range, no look-ahead smooth bell-
shaped acceleration/deceleration before interpolation is performed.
(*1) Parameter No. 8416 for look-ahead acceleration/deceleration before
interpolation (cutting feed) or parameter No. 1621 for
acceleration/deceleration before interpolation for linear rapid traverse and
optimum-torque acceleration/deceleration.
