FANUC Series 16i /18i Additional Manual Page 171

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
171/190
1420 Rapid traverse rate for each axis
[Data type] Two-word axis
[Unit of data, Valid data range]
Valid data range
Increment system Unit of data
IS-B IS-C
Millimeter machine 1 mm/min
30
∼240000 6∼100000
Inch machine 0.1 inch/min
30
∼96000 6∼48000
Rotation axis 1 deg/min
30
∼240000 6∼100000
Set the rapid traverse rate when the rapid traverse override is 100% for each
axis.
The reference acceleration is calculated with this parameter and No.1773.
1773
Time constant T or T
1 for each axis used for linear acceleration/deceleration
or bell–shaped acceleration/deceleration in rapid traverse of
Optimum torque acceleration/deceleration
[Data type] Word axis
[Unit of data] msec
[Valid data range] 0 to 4000
Specify a time constant used for acceleration/deceleration in rapid traverse.
(1)
When the parameter HRB(No.19504#0) is set to 0,
Set the time constant for linear acceleration/deceleration.
If this parameter is set to 0, parameter No.1620 is used.
(2)
When the parameter HRB(No.19504#0) is set to 1,
Bell–shaped acceleration/deceleration for rapid traverse is selected.
Set the time constant T1 for Bell–shaped acceleration/deceleration.
If this parameter is set to 0, parameter No.1620 is used.
The time constant T2 for Bell–shaped acceleration/deceleration is set to
parameter No.1774.
(3)
When the Optimum torque acceleration/deceleration is provided,
The reference acceleration is calculated with this parameter and parameter
No.1420. If this parameter is set to 0, parameter No.1620 is used for this
calculation. In case of the calculated acceleration is over 100000.0 mm/sec
2
,
reference acceleration is clumped 10000.0 mm/sec
2
. In case both this
parameter and No.1620 are set to 0, next value is applied for the reference
acceleration.
1000.0mm/sec
2
, 100.0inch/sec
2
, 100.0deg/sec
2
In case both this parameter and No.1620 for all axes are set to 0, Optimum
torque acceleration/deceleration is disable.
