FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
78/190
2.17.4 Parameter specification example
When specifying the parameters related to a machine configuration, see the
table below.
For the machine shown in Fig.2.17.1, set the parameters to the settings listed in
the table.
Axis numbers is supposed to be as follows: X = 1, Z = 2, C = 3, Y = 4, and B = 5
Parameter
No.
Setting value
(IS-B)
Description
19610 5 (B) Axis number of the tool rotation axis (first set)
19611 2 (Z) Axis number of linear axis 1 of the tool rotation axis (first set)
19612 1 (X) Axis number of linear axis 2 of the tool rotation axis (first set)
19613 4 (Y) Axis number of linear axis 3 of the tool rotation axis (first set)
19614 0 Angle of the tool rotation axis (first set)
19615 0 Axis number of the tool rotation axis (second set)
19616 0 Axis number of linear axis 1 of the tool rotation axis (second set)
19617 0 Axis number of linear axis 2 of the tool rotation axis (second set)
19618 0 Axis number of linear axis 3 of the tool rotation axis (second set)
19619 0 Angle of the tool rotation axis (second set)
19620 0 Reference angle of the tool rotation axis (first set)
19621 0 Reference angle of the tool rotation axis (second set)
19622 -90000 Reference angle of the tool axis on the plane of linear axes 2 and 3 (RA)
19623 0 Reference angle of the tool axis on the plane of linear axes 3 and 1 (RB)
19720 1 (X) Axis number of linear axis 1 (first axis of the workpiece coordinate system)
19721 4 (Y) Axis number of linear axis 2 (second axis of the workpiece coordinate system)
19722 2 (Z) Axis number of linear axis 3 (third axis of the workpiece coordinate system)
19723 3 (C) Axis number of the table rotation axis (first set)
19724 2(Z) Axis number of the linear axis corresponding to the table rotation axis (first set)
19725 0 Axis number of the table rotation axis (second set)
19726 0 Axis number of the linear axis corresponding to the table rotation axis (second set)
19730 0 Reference angle of the table rotation axis (first set)
19731 0 Reference angle of the table rotation axis (second set)
Note
1. Set 0 for the table rotation axis of the second set and for the tool rotation axis of
the second set.
2. The three basic axes to make up the workpiece coordinate system of
parameters No. 19720 to 19722 must be used to make up that of parameters
No.19611 to 19613.
3. The axis number of the table rotation axis (first set) must not be the same as
the axis number of the tool rotation axis (first set).
The table rotation axis (first set) and the tool rotation axis (first set) must not
rotate about the same axis.
