FANUC Series 16i /18i Additional Manual Page 158

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
158/190
Linear axis about which a
rotation axis rotates
Value set for parameter
No.19724 or 19726
Rotation direction of the rotation axis Direction with an angular
displacement of 0
Linear axis 1 Axis number of
linear axis 1
Forward direction of linear axis 2 to
forward direction of linear axis 3
Forward direction of
linear axis 2
Linear axis 2 Axis number of
linear axis 2
Forward direction of linear axis 3 to
forward direction of linear axis 1
Forward direction of
linear axis 3
Linear axis 3 Axis number of
linear axis 3
Forward direction of linear axis 1 to
forward direction of linear axis 2
Forward direction of
linear axis 1
If the rotation direction of the rotation axis is the reverse of what is described in
the table above, set a negative value for parameter No.19723 or 19725.
If the direction with an angular displacement of 0 differs from what is described
in the table above, specify parameters No.19730 and 19731, assuming that the
angle of the rotation axis in relation to the direction described in the table above
as the reference angle.
19730 Reference angle of the rotation axis
in the tool radius compensation for 5-axis machining (first set)
19731 Reference angle of the rotation axis
in the tool radius compensation for 5-axis machining (second set)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 - +99999999
Set the angles of reference positions on the rotation axes used for the tool radius
compensation for 5-axis machining.
19734 Workpiece coordinates of the origin of the table coordinate system
in the tool radius compensation for 5-axis machining
[Data type] 2 Word axis
[Unit of data]
increment system IS-B IS-C unit
Millimeter machine 0.001 0.0001 mm
Inch machine 0.0001 0.00001 inch
[Valid data range] -99999999 to +99999999
Set the workpiece coordinates of the origin of the table coordinate system used
for the tool radius compensation for 5-axis machining. Specify the parameter for
the three axes specified for parameters No.19720 to 19722. The intersection of
two rotation axes is assumed to be the origin of the table coordinate system.
