2.15.3 Programmable Mirror Image
• Outline
By a programmed command, the mirror image function can be used for each axis.
The mirror image function selected by a CNC external switch or CNC setting is
executed after the programmable mirror image function is executed.
This function can use only in the AI HPCC / AI NANO HPCC mode.
This function is an additional option.
• Format
G05 P10000 ; : Starting of AI HPCC / AI NANO HPCC mode
G51.1 X_ Y_ Z_ ; : Starting of programmable mirror image mode
:
:
G50.1 X_ Y_ Z_ ; : Ending of programmable mirror image mode
G05 P0 ; : Ending of AI HPCC / AI NANO HPCC mode
This function is that the mirror image is effective as the mirror was put on the
position of X, Y, and Z commanded with G51.1.
The mirror image is canceled by X, Y, and Z commanded with G50.1.
In this case, the commanded value does not care about any value.
• Notes concerning programmable mirror image
Operation of program
Movig direction
Instruction form
Warning
Applying a mirror image to one of the axes on a specified plane changes as
follows:
2. Circular command: The direction of rotation is reversed.
3. Cutter compensation: The direction of offset is reversed.
4. Coordinate system rotation: The direction of rotation is reversed.
Warning
Relation between move command, machine movement, and coordinate value is
as follows in the programmable mirror image.
Move command Machine travel
Machine
coordinate
Relative
coordinate
Absolute
coordinate
+−−−−
−++++
Note
The first move command coming after G50.1 or G51.1 must be specified with
absolute values.
