3.13 Parameters of Look-ahead Acceleration and Deceleration before Interpolation
#7 #6 #5 #4 #3 #2 #1 #0
1603 RSB
[Data type] Bit
RSB Set the type of acceleration/deceleration before interpolation.
0: Linear acceleration/deceleration.
1: Bell-shaped acceleration/deceleration.
#7 #6 #5 #4 #3 #2 #1 #0
8402 BDO DST BLK NBL
[Data type] Bit
BDO,NBL Set the type of acceleration/deceleration before interpolation.
BDO NBL Meaning
00
Acceleration/deceleration prior to interpolation is of linear
type
11
Acceleration/deceleration prior to interpolation is of bell-
shaped type
BLK Be sure to set to 0.
DST Be sure to set to 1.
Note
As for either setting parameter No.1603#3 or No.8402#7 and # 1, the
operation of the acceleration/deceleration becomes the same.
