FANUC Series 16i /18i Additional Manual Page 55

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
55/190
The velocity command can be given with two ways according to the setting of
the parameter No. 1407#4 (RHT) as the following table.
RHT(No..1407#4)
01
Tangent Speed of the arc Synthetic speed of the linear axis and
tangent speed of the arc
CNC interpolates including the rotary axis and controls the pivot point so that
the tool center point moves along the arc on the workpiece. The end point of the
tool center point is the point specified in the programming coordinate system.
Note
You must use G00 or G01 command in case a tool center point doesn't
move, or only rotary axes move.
