FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
168/190
8456 Area–2 override
[Data type] Word
[Unit of data]
%
[Valid data range] 0 to 100 (Standard setting: 80)
This parameter specifies an override in area 2 of velocity calculation considering
the cutting load.
8457 Area–3 override
[Data type] Word
[Unit of data]
%
[Valid data range] 0 to 100 (Standard setting: 70)
This parameter specifies an override in area 3 of velocity calculation considering
the cutting load.
8458 Area–4 override
[Data type] Word
[Unit of data]
%
[Valid data range] 0 to 100 (Standard setting: 60)
This parameter specifies an override in area 4 of velocity calculation considering
the cutting load.
8464 Initial feedrate for automatic feedrate control
[Data type] 2-word
[Unit of data, Valid data range]
Valid data range
Increment system Unit of data
IS-B IS-C
Millimeter machine 1 mm/min
10
∼240000 1∼100000
Inch machine 0.1 inch/min
10
∼96000 1∼48000
Rotation axis 1 deg/min
10
∼240000 1∼100000
This parameter sets the initial feedrate for automatic feedrate control.
In automatic feedrate control, the initial feedrate set with this parameter is used
at the beginning if no F command is specified in the program.
Usually, set the maximum cutting feedrate (specified in parameter No. 1422).
8465 Maximum allowable feedrate for automatic feedrate control
[Data type] 2-word
[Unit of data, Valid data range]
Valid data range
Increment system Unit of data
IS-B IS-C
Millimeter machine 1 mm/min
10
∼240000 1∼100000
Inch machine 0.1 inch/min
10
∼96000 1∼48000
Rotation axis 1 deg/min
10
∼240000 1∼100000
This parameter sets the maximum allowable feedrate for automatic feedrate
control. Usually, set the maximum allowable cutting feedrate (set in parameter
No. 1422).
